6al 4v Titanium Tubing: The Durable and Versatile Choice
Ti 6Al 4V alloy, also known as Ti-64, is a seamless or welded pipe made of Ti 6Al 4V alloy, which contains 6% aluminum, 4% vanadium, and the rest is titanium, which is an α-β type titanium alloy. Ti 6Al 4V tube is one of the most widely used titanium alloys due to its excellent strength, toughness and corrosion resistance. It is especially suitable for various structural and industrial applications requiring high strength and low weight.
Our 6Al 4V Titanium Tubing is produced in compliance with ASTM B338 and ASME SB338 standards, ensuring the highest quality and consistency in the product. Tubing is available in a variety of sizes and thicknesses according to specific customer requirements. In addition, we also have a large stock of 6Al 4V titanium tubes, which can provide fast delivery and competitive prices to global customers.
In terms of cost, the price of Ti 6al 4v may vary depending on the size and complexity of the pipe. However, due to its excellent properties and long service life, it is often considered a cost-effective material in the long run.
| Product Name | 6al 4v（Grade 5）titanium tubing |
| Standard | ASTM B338,ASTM B861 |
| Size | Dia 6.0mm ~114.3mm,length is 18000mm (Max). |
| Test | Water pressure test,Ultrasonic test,X-ray test,Eddy current test,Flaring and Flattening test. |
| Certificate | EN10204 3.1/3.2 as required. |
Material Grade Standards
6al 4v titanium tubing is typically manufactured according to various industry standards, such as ASTM B338 and AMS 4943. These standards define the chemical composition, mechanical properties, and testing requirements for titanium tubes.
The chemical composition of 6al 4v titanium tubing is as follows:
- Titanium: 88.6%
- Aluminum: 6.0%
- Vanadium: 4.0%
- Iron: 0.25%
- Oxygen: 0.20%
- Carbon: 0.08%
- Nitrogen: 0.05%
The mechanical properties of 6al 4v titanium tubing are as follows:
- Tensile strength: 110 ksi (758 MPa)
- Yield strength: 100 ksi (689 MPa)
- Elongation: 10%
- Hardness: 36 HRC
6al 4v titanium tubing has a wide range of applications, including:
- Aerospace: 6al 4v titanium tubing is used in various aircraft components, such as landing gear, engine parts, and structural frames.
- Motorsports: The tubing is used in high-performance racing cars and motorcycles due to its lightweight and high strength properties.
- Medical: 6al 4v titanium tubing is used in medical implants and prosthetics due to its biocompatibility and hypoallergenic properties.
- Chemical processing: The tubing is used in chemical processing plants due to its excellent corrosion resistance properties.
- Marine: 6al 4v titanium tubing is used in marine applications due to its resistance to saltwater and other harsh environments.
About TSM：
At TSM Technology Co Ltd we pride ourselves on our commitment to supplying high quality Titanium products at competitive prices. Our team of experts is on hand to help customers choose the right product for their unique needs. Whether your new project requires 6Al 4V titanium tubing or you need to replenish your stock, we have the confidence and expertise to meet your needs.
In conclusion, 6Al 4V Titanium Tube is an excellent product that offers a range of advantages to various industries. TSM Technology Co Ltd is a leading supplier of this material, offering competitive prices, fast delivery and excellent customer service to customers worldwide. Please contact us today to learn more about our products and services.
