Titanium Grade 5 Bars
TSM as a stockist always keep ASTM B348 6al4v Titanium Grade 5 Bars in stock with the standard dimension.
6al4v alloy covered about 60% usage of titanium industry,with our big stock support,TSM will be your best choice.
Delivery always in 5-7 days.
Payment terms: T/T, L/C, Paypal or as required
Description
ASTM B348 Grade 5Titanium Round bar - manufacturer, supplier, factory
Titanium Grade 5 Bars, also known as ASTM B348 Gr5 or 6Al-4V Titanium bar, are becoming increasingly popular for their strength, lightweight properties and corrosion resistance. As a leading manufacturer, supplier and factory of titanium bars, we at TSM Technology Co. Ltd. offer premium quality products at a competitive price and stock a range of sizes and shapes to meet the diverse needs of our customers.
Product Description
Titanium Grade 5 Bars are made of Ti-6Al-4V alloy, which is a combination of 6% aluminum and 4% vanadium. It is one of the most common titanium alloys used for industrial and aerospace applications due to its high strength-to-weight ratio, corrosion resistance and ability to perform in extreme temperatures.
Our Titanium Grade 5 Bars are manufactured using advanced technologies such as precision forging, hot rolling, and cold drawing to ensure high-quality end products. We offer various types of 5th grade titanium bars such as round bars, square bars, hexagonal bars and flat bars, which can be customized according to clients' specifications.
|
Commodity Name |
Titanium Grade 5 Bars |
|
Standard |
ASTM B348, ASTM F136, ASTM F67,AMS4928 |
|
Titanium Grade |
Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,Gr9,Gr23 |
|
Diameter |
Dia:Φ 6mm--Φ300mm Length: 100mm--6000mm |
|
Surface |
Polishing |
|
Tech |
Forged, Rolling |
|
Shape |
Round bar, square bar, hexagonal bar |
|
Delivery status |
Heat treatment Annealing treatment Aged+Solutions(Require） |
Alternative material called by difference standard
|
ISO Standard |
Composition |
France Standard |
Russian Standard |
DIN Standard |
JIS Standard |
UNS Standard |
|
Grade5 |
6al4v |
TA6V |
OT4 |
3.7165 3.7164 |
TAP6400 |
UNS R56400
|
Chemical components below:
| Ti Gr 5 |
N |
C |
H |
Fe |
O |
Al |
V |
Pa |
Mo |
Ni |
Ti |
|
0.05 |
0.08 |
0.015 |
0.40 |
0.20 |
5.5~6.75 |
3.5~4.5 |
/ |
/ |
/ |
balance |
Titanium Grade 5 Mechanical Property
| Ti Gr 5 |
Tensile strength(min) |
Yeild strength(min) |
Elongation(%) | ||
|
ksi |
MPa |
ksi |
MPa | ||
|
130 |
895 |
120 |
828 |
10 |
|
Titanium Bar Gr5 - Applications
Grade 5 Titanium Round Bars are used in a wide range of applications due to their unique properties. Some of the most common applications include:
• Aerospace and Aviation: Grade 5 Titanium Round Bars are used in the manufacture of aircraft parts such as landing gear, engine components, and airframe structures. These bars are lightweight, strong, and resistant to corrosion, making them ideal for aerospace applications.
• Marine Industry: Titanium Grade 5 Bars are also used in the marine industry due to their corrosion resistance properties. They are used to manufacture propeller shafts, rudders, and other components that are exposed to seawater.
• Medical Industry: Grade 5 Titanium Round Bars are biocompatible and non-toxic, making them suitable for medical implants such as dental implants, artificial joints, and bone plates. They do not react with bodily fluids, ensuring that they do not cause any adverse effects on patients.
• Chemical Engineering: Titanium Grade 5 Bars are resistant to corrosion by a wide range of chemicals, making them suitable for use in the chemical processing industry. They are used to manufacture chemical reactor vessels, heat exchangers, and piping systems.
Why Choose TSM Technology Co. Ltd?
At TSM Technology Co. Ltd, we are committed to providing our clients with high-quality Grade 5 Titanium Round Bars that meet their specific requirements. We specialize in providing customized solutions, rapid delivery, and excellent customer service. We also offer competitive prices, making us one of the most trusted suppliers of titanium bars in the global market.
TSM Technology is one of Asian leading suppliers of high performance titanium base in China,specializing in mill products such as titanium and nickel bars, rods, plates, forgings, fasteners and tubes. And refractory metal processing work for around 20years.
