Titanium Flat Wire: Precision Engineered for Extreme Missions
Titanium Flat Wire from TSM Technology Co. represents the pinnacle of metallurgical precision. Combining the extraordinary strength-to-weight ratio of titanium with ultra-fine dimensional tolerances, our flat wire is the preferred choice for high-stakes applications in medical implants, aerospace fasteners, and chemical processing. As a leading manufacturer with over 20 years of expertise, TSM ensures every spool meets the most stringent international standards, including ASTM, AMS, and ISO.
What is Titanium Flat Wire?
Titanium Flat Wire is a specialty profile produced by precision rolling or drawing round titanium wire into a flat, rectangular, or ribbon-like cross-section. Unlike standard round wire, the flat profile offers increased surface area and directional strength, making it ideal for springs, brackets, and electrical components.
At TSM Technology, we specialize in producing both Commercially Pure (CP) and Alloyed titanium wire. Our wires inherit the best properties of titanium: exceptional corrosion resistance, biocompatibility, and low density (approx. 43% lighter than steel). Whether you need Grade 2 for chemical stability or Grade 5 for structural integrity, our flat wire provides the mechanical consistency required for automated manufacturing processes.
| Property | Specification Range |
| Thickness | 0.025 mm – 5.0 mm |
| Width | 0.10 mm – 20.0 mm |
| Width/Thickness Ratio | Up to 15:1 |
| Tolerance (Thickness) | $\pm 0.005 mm$ to $\pm 0.02 mm$ |
| Surface Finish | Polished, Pickled, or Bright Annealed |
| Temper | Annealed (Soft), 1/4 Hard, 1/2 Hard, Full Hard |
| Packaging | Spools (DIN 125, DIN 160, DIN 250), Coils, or Cut Lengths |
Material Grades & Mechanical Integrity
•Grade 1 & 2 (Commercially Pure): These alpha-phase materials offer unparalleled corrosion resistance in seawater and chemical environments. It strikes an optimal balance between strength and ductility, making it the most common choice for Titanium Flat Wire in general engineering.
•Grade 5 (Ti-6Al-4V): The flagship alloy for the aerospace sector. Combining 6% Aluminum and 4% Vanadium, it provides a high strength-to-weight ratio and excellent fatigue resistance at temperatures up to 400°C.
•Grade 23 (Ti-6Al-4V ELI): Specifically produced with 'Extra Low Interstitials' to maximize fracture toughness. This is the primary choice for orthopedic implants and dental fixtures.
•Custom Alloys: We also roll Grade 7 (Palladium-enhanced) and Grade 12 (Mo-Ni alloyed) for extreme chemical processing environments.
Compliance with International Standards
•Aerospace: AMS 4928, AMS 4911
•Industrial: ASTM B348, ASTM B265, DIN, JIS
•Medical: ASTM F67, ASTM F136
Every shipment is accompanied by a full Material Test Certificate (MTC) and optional SGS or third-party reports, guaranteeing 100% traceability.
The Precision of Cold Rolling: Technical Advantages
TSM uses advanced cold rolling technology to transform titanium round wire into precision flat wire. Unlike hot processes, cold rolling occurs below the recrystallization temperature, resulting in several key advantages:
1.Work Hardening: Increases the metal's strength by up to 20%.
2.Surface Finish: Achieves a mirror-like bright finish or custom pickled surface.
3.Dimensional Accuracy: We maintain tolerances as tight as ±0.005mm on thickness and ±0.01mm on width.
Our process includes vacuum annealing to ensure the crystalline structure is stabilized after cold work, preventing brittleness while maintaining high tensile properties.
Custom Profiles and Dimensions
No two projects are identical. TSM offers custom shaped and flat wire profiles tailored to your mission. We can produce widths from 0.5mm up to 20mm and thicknesses from 0.05mm up to 5mm. Our engineering team provides technical support for custom bending, welding, and cutting services to ensure the wire integrates seamlessly into your production line.
TSM solves your procurement challenges:
We understand the various difficulties and challenges our clients face when purchasing titanium alloy materials: supply chain bottlenecks, inconsistent quality, and hidden costs. TSM directly addresses these issues:
•Quality Consistency: Every batch is tested in-house. No more surface defects or diameter variations.
•Optimized Delivery Cycles: We have three factories, ensuring a stable monthly output of 300 tons. For urgent orders, we can arrange expedited production.
•Total Cost of Ownership (TCO): We provide competitive factory pricing directly from China, eliminating middleman markups while providing Western-standard certifications.
Supply Chain Excellence and Logistics
Logistics shouldn't be your headache. TSM manages the entire process from customs duties to final delivery. We offer flexible payment terms (T/T, L/C) and risk-free collaboration with free samples for qualified projects. Our English-speaking sales team ensures seamless communication across time zones.
